Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized

Certification
China Shenzhen Jetacon Technology Ltd certification
China Shenzhen Jetacon Technology Ltd certification
I'm Online Chat Now

Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized

Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized
Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized

Large Image :  Pitch 1.27mm 2.0mm 2.54mm Male Angle Pin Header PCB SMT Connector Single Dual Triple Row Customized

Product Details:

Place of Origin: Guang Dong
Brand Name: Jetacon
Certification: UL, CE
Model Number: 1.00-to-2.54 Pin Header

Payment & Shipping Terms:

Minimum Order Quantity: 1000 Pieces
Price: US $0.99 / Piece
Packaging Details: Standard Export Carton
Delivery Time: 7-20 working days
Payment Terms: T/T, L/C, Paypal, Payoneer
Supply Ability: 1KK poles monthly
Detailed Product Description
Number Of Contacts: 4 - 80 Current: 3A
Type: Angle Pin Male

Current rating:3A
Withstand Voltage: 500VAC/minutes
Working temperature: -40 Celsius degree ~ 105 Celsius degree

Material:
Insulaor material: Nylon 6T,resist high temperature or PBT
Contact Material: Copper Alloy



Contact Plating:

Gold over nickel

Tin / Gold Flash / Gold 3µ'' / Gold 5µ'' / Gold 10µ'' / Gold 15µ'' / Gold 30µ'' /

Tin over nickel


Insulator height:1.5/2.0/2.54mm

No of pins:

Single: 2P~40P

Dual: 2P~80P

triple:3P~120P

Contact us for pdf drawings and you can see the detailed dimension.

PCB Header Mounting options:

1. Through hole mount

2. Right angle Through hole mount

3. Surface Mount ( with pick up cover for pick and place machine).


How to choose a PCB Header?

a. Pitch? Tell us the pitch of header such as 1.27mm , 2.0mm or 2.54mm pitch.

b. Insulator layer ? Tell us you want is single insulator or double insulator or triple layer insulator

c. Number of pins? Tell us the number of pins and single or double row you need

d. Mounting type ? Vertical Straight or Right angle Through hole or Vertical SMT to PCB

e. Package? If need Surface mount, tell us the package is tube or Tape and reel package.

f. Other connectors ? Pin header is male board end connector, tell us if you need female header for a board to board connection or board to wire connection.






Contact Details
Shenzhen Jetacon Technology Ltd

Contact Person: Mr. Jetacon Technology Limited

Fax: 86-0755-89571454

Send your inquiry directly to us (0 / 3000)
