| Channel: | 16 | Voltage Output: | DC24V |
|---|---|---|---|
| Current Output: | 16A |
Function Description:
Din Rail Mounting
8 Relay open Close ports
Can have up8Separate areas
Each Channel Having a lamp protection delay
Each channel start with a delay
Each channel Have Overload protection
Each channel Start button has priority
Fire has played a strong function (need fire protection system provides normally open dry contact signal)
Each Channel has a status indicatorLED
Overheating protection function
Can Remote programming and management
| parameters: | |||||
| Working conditions | Voltage | DC24V | Load capacity | Number of Channels | 8 channel |
| Power | 30mA ~ 450mA | Load voltage | AC250V | ||
| Temperature | -20 ~ 60 | Load current per channel | 16A (resistive) | ||
| Relative humidity | 20% to 90% (non-condensing) | Overload | Have | ||
| Storage conditions | Temperature | -30 ~ 70 | Other | Signal | Modbus / RS485 |
| Relative humidity | 20% to 93% (non-condensing) | Dimensions | 72mm × 68mm × 62mm |
